ENGINE: Kubota (tier 3 certified) diesel engine, D1005, 3 cylinder liquid cooled diesel engine (16 hp @

1800 rpm), mounted radiator, coolant recovery tank, air cleaner, Chalwyn automatic and manual air intake

shutdown, muffler, Super Trapp spark arrestor, 12 volt electric start, electric fuel pump, Racor primary fuel

filter, secondary spin on fuel filter, F.W. Murphy engine controls, hi temp and low oil shutdown, hour meter,

EZ oil drain valve

GENERATOR: Newage 8KW dedicated single phase, 1800 rpm generator, 120/240V, AC brushless, epoxy

coated, automatic voltage regulator, self excited, dynamically balanced rotor, fan cooled

LIGHTING: 4 – Dialight High Bay LED Lights

RECEPTICLES: 3 – 110V, 1 – 240V Kilopak explosion proof receptacles, (Class1 & 2), circuit breaker

protected, 2 tumbler switch for on/off light control, ground fault protection for receptacles

SKID: Structural steel skid with 3”x8”x3/16” box tubing base, 2”x2”x 3/16” tubing roll frame, 4 corner lift

pad eyes with 572 plate strength, ¾” width, 7/8” shackle pin hole drilled, , 4”x10”x3/16 box tubing forklift

pockets, 2” above bottom of skid, expanded metal top, beveled drip pan with bottom drain, aluminum enclosure

with side inspection doors, stableflex neoprene vibration isolators, 30 gallon aluminum CG approved fuel tank

with fuel gauge, aluminum storage box, stainless steel hardware.

BOOM: (PATENT PENDING) Structural steel all welded and galvanized 16ft telescoping boom, single

stage with Teflon guides, rotating mast, 360 degree lighting capability, hand winch with locking break, ¼”

cable with stainless steel pulleys, locking pin when boom is extended, expanded metal winch guard

DIMENSIONS: L 64” x W 62” x H 84”

WEIGHT: 2,800 LBS./ 3,100 LBS.
